| Resolution |
1280 x 720 |
| Brightness (typical) |
1200 ANSI Lumens (vivid mode) |
| Uniformity |
85% (corner to center) |
| LCD Panel System |
0.7" TFT Poly-Silicon x 3 (16:9) |
| Number of Pixels |
2,764,800(921,600 x 3) |
| Contrast Ratio |
10,000:1 (vivid mode) |
| Projection Image (diag.) |
40" - 300" |
| Aspect Ratio |
16:9 |
| Throw Distance |
3.9' - 30.2' |
| Zoom/Focus |
1x to 2.0x, Manual driven |
| Lens Shift |
Manual (Up/Down/Left/Right) |
| Up/Down/Left/Right Ratio |
Up/Down: 3: -1 ~ -1:3 (-1V/Center/+1V)
Left/Right: 10:0 ~ 0:10 (-0.5H/Center/+0.5H) |
| Digital Keystone Correction |
Vertical: +/- 20° |
| Projection System |
Dichroic mirror & 4P prism system w/ PBS |
| Projection Lens |
F2.0 ~ 3.0 / f0.8” ~ 1.7” |
| Lens Throw Ratio |
1.35 ~ 2.7:1 |
| Projection Lamp |
145W UHP |
| Scanning Frequency |
H: 15~80kHz, V: 50~100Hz
(auto sense/select) |
| Dot Clock |
100 MHz |
| HDTV signal |
480i/480p/575i/575p/720p/1080i/1080p (HDMI input only) |
| Color System |
PAL/SECAM/NTSC/NTSC4.43/PAL-M/PAL-N |
| Computer Compatibility |
WXGA/SXGA/XGA/SVGA/VGA/MAC |
| Voltage |
100V-240V AC; 50/60Hz (auto voltage) |
| BTU Rating |
717 |
| dB Rating |
22 dBA (Eco mode) |
| Power Consumption |
210W/185W (Nomal/Eco) |
| Dimensions (WxHxD) |
15.0” x 5.0” x 12.0” (not including protrusion) |
| Net Weight |
11.0 lbs |
| User Maintenance |
Clean air filters, replace lamp assembly |
Input Terminals
Component Video 1 |
Y, Pb/Cb, Pr/Cr (RCA x 3) |
| Component Video 2 |
Y, Pb/Cb, Pr/Cr (RCA x 3) |
| S-Video |
S-Video (Mini DIN 4-pin x 1) |
| Composite Video |
Video (RCA x 1) |
| Computer |
Analog RGB (D-Sub 15) |
| HDMI |
HDMI (19-pin) x 2 |
| Communication |
RS-232C/ Service Port (Mini DIN 8-pin) |
| Included Accessories |
Owner's Manual(Quick manual & CD ROM); Illuminated Infrared Remote Control; AC Power Cord (6.6’); 2 AA batteries; Air blower |
| Optional Accessories |
610 322 5998 – Replacement Lamp
945 087 1451 – Replacement Remote
POA-MCSRL – Serial Control Cable |
| FCC Rating |
Class B, UL Listed |
| Warranty |
3-years parts & labor; 90-days lamp (original);30-days lamp
(replacement) Quick Repair Program under warranty |
