Brightness |
2000
ANSI Lumens Standard Mode
1600 ANSI Lumens Low Power Mode |
Display
Resolution
(Native) |
XGA
(1024 x 768) |
Resolution Capability
(Maximum) |
SXGA+
(1400 x 1050) |
|
Compatibility |
PC, Mac
and Work Station |
|
Frequency Range |
fh 15 -
70 kHz/fv 43 - 85 Hz |
Weight
/ Dimensions
(w x h x d) |
6.4
lbs. / 11.7" x 3.2" x 9" |
|
Unique
Feature(s) |
Low
Power Shutdown |
|
Size /
Type |
0.79"
TFT LCD |
|
Dot
Clock |
12 -
108 MHz |
|
PC
Compatibility |
up to
SXGA+ (1400 x 1050) |
|
Mac
Compatibility |
up to
1280 x 1024 with ImageACE Resizing |
|
WS
Compatibility |
up to
SXGA+ (1400 x 1050) |
|
Video
System |
NTSC
3.58, 4.43 / PAL (50/60) / PAL-M / PAL-N /SECAM |
|
DTV/HD
Compatibility |
1080i,
720p, 580p / 580i / 540p, 480p Component Video and 480i |
|
Video
Circuitry |
Interlaced/Progressive Scan |
|
Resizing |
VGA
(640 x 480)
up to SXGA+ (1400 x 1050) |
Center
to Corner Ratio
(average) |
90% CCR |
|
Contrast Ratio |
400:1 |
|
Lens
Type |
Recessed 1:1.2x Manual Zoom and Focus |
|
PC
Control |
RS-232C |
|
Remote
Control |
IR |
|
IR
Carrier Frequency |
38 kHz |
|
Audio
System |
1.0
Watt Monaural |
|
Lamp |
180
Watt SHP End User Replaceable |
|
Lamp
Life (average) |
Standard Mode: 3000 hrs.
Low Power Mode: 4,500 hrs. |
|
Fan
Noise |
37 dB /
33 dB Low Power Mode |
|
Power
Source |
110-240
VAC, 50/60Hz |
|
Power
Consumption |
Standard Mode: 240 Watts
Low Power Mode: 200 Watts |
|
Limited
Warranty |
3 Years
Parts/Labor & 2 Years Sharp Express Repair. Lamp 90 Days |
|
Computer Inputs |
(1) RGB
/ Component 15 pin HD (shared) |
|
Video
Inputs |
(1)
Composite RCA, (1) S-Video - 4 pin DIN |
|
Min/Max
Screen Size |
40" -
300" |
|
Min/Max
Projection Distance |
4' 3" -
39' 0" |
