Supplied Accessories - Remote Commander (RM-PJM12), Size AA Batteries,
HD D-Sub 15 pin Cable, USB Cable, Carrying Case, Air Filter,Operating
Instruction, Quick Reference Guide
SONY VPLCS5 Portable Video Lcd Projector
The VPL-CS5 is one of the latest additions to the ranks of high-quality Sony
projectors, and is ideal for handling presentations when you are always on
the move. Compact and light enough to be easily carried, The VPL-CS5 projector
is an excellent choice. The VPL-CS5 provides a brightness of 1800 ANSI lumens,
SVGA (800 x 600) resolution and a full range of functions. The VPL-CS5 meets
the demands of the road and in the boardroom.
FEATURES - sony vplcs5 portable video lcd projector
of 1800 ANSI lumens The portable SVGA VPL-CS5 accomplishes best-in-class brightness.
The bright VPL-CS5 adopts Sony original virtual light system with the all-new
super high aperture liquid crystal panel and newly developed bright 165W UHP
The all-new elliptical reflector with ultra smooth surface combined with a
concave lens enables very small light source and accomplish very high light
collection efficiency. This provides the audience with a clear, crisp and
bright image every time.
Auto Setup Just turn on the power and the following sophisticated functions are initiated.
Powered lens protector
When power is switched on, the powered lens protector opens automatically.
You will never waste time looking for a missing lens cover - it is always
safe on the projector.
Powered tilt adjuster
and Auto Keystone Correction
A power operated tilt adjuster sets the projector's shooting angle, and keystone
distortion is automatically corrected according to the tilt angle.
The tilt angle is adjustable from the remote control unit and the new setting
retained in memory. Keystone distortion can be corrected up to a projector
tilt angle of 15 degrees by the remote control unit.
This means that images can be projected with the correct geometry even where
installation space is limited.
The previous setting of each function is held in memory and recalled automatically
Smart APA (Auto
No need to adjust your PC computer or portable Sony VPL-CS5 LCD Projector
for optimum picture performance, the Smart APA function ensures that the display
is automatically sized and adjusted for optimum picture performance whatever
the input signal.
Auto Input Search Images are projected instantly. This is because the SVGA sony VPL-CS5
LCD projector automatically detects the presence of a connected input signal
when you connect the devise or put on the power. You don't have to manually
select the input via the input select button.
Inputs are provided
for composite video, S-video and (Y/R-Y/B-Y)/RGB component signals.
The portable SONY VPLCS5 video projector has a built-in scan converter that
allows it to accept composite video, component video or RGB video input signal.
USB Input is also available for wireless mouse control. The bright VPL-CS5
LCD Projector accepts signals up to XGA resolution.
Want to emphasize a point in your presentation! The Sony VPLCS5 video projector
Digital Zoom feature allows any designated section of the projected image
to be zoomed in up to 4X larger.
style and portable
Sony continues to develop innovative design and the SONY VPL-CS5 is no exception!
The SONY VPL-CS5
LCD Projector sets new standards in visual styling with its simple and elegant
external design. With just the buttons most commonly used located on a sleek
top panel, the VPL-CS5 overall appearance is flat and smooth, making it both
attractive and easy to carry. Other buttons and the connectors are concealed
behind a cover when they are not being used, adding to the smart appearance.
The SONY VPLCS5
is light, only weighing 2.7 kg (5 lb 6 oz).
The "Freeze" function on the portable bright VPL-CS5 video projector
allows the presenter to freeze-frame their presentation on the projector,
allowing the audience to see only that slide, while the presenter can successfully
toggle their documents on the PC desktop. When ready, the presenter can depress
the freeze function and the audience is non the wiser!
Keystone Correction Keystone distortion of up to 15 degrees can be digitally corrected. Images
can be projected with the correct geometry even in the limitation of space.
- sony vplcs5 portable video lcd projector
SVGA (800 x 600)
1800 ANSI lumens
No. of Colors
0.7-inch p-Si TFT LCD
panel x 3
PC and Macintosh computers
NTSC, PAL, SECAM, NTSC
4.43, PAL-M, PAL-N
600 TV lines
Composite Video (Single
RCA) x 1
S-Video (Mini DIN 4-pin
(Y/C)) x 1
Computer, Analog RGB
(Standard VGA, mini D-Sub 15-pin) x 1
USB Mouse x 1
Computer Audio (Stereo
mini jack) x 1
Max. 1 W (mono)
1.2 times zoom lens, F1.8
to 2.2, f28.2 to 33.8 mm
