| PDP Panel Type |
60" |
| Display Area |
59.5" |
| Aspect Ratio |
16:9 |
| Native Display Resolution |
1366 × 768 (WXGA) |
| Pixels (H × V × 3) |
3,147,264 |
| Brightness |
1200 cd/m2 |
| Contrast Ratio |
12,000:1 |
| Viewing Angle (H x V) |
160 × 160 |
| Color Reproduction (R,G,B) |
10 Bits |
| Filter Type |
Glass Filter |
| Image Sticking Minimization |
White Wash, Pixel Orbiter, Inversion |
| Lifetime |
Approx. 60,000 hours to half brightness (MTBF) |
| |
|
| VIDEO |
|
| |
|
| Max. Input Resolution |
1600 × 1200 @ 60Hz (Analog)
1280 × 1024 @ 60Hz (Digital) |
| Recommended Resolution |
1366 × 768 @ 60Hz (Analog/Digital) |
| H-Scanning Frequency |
30 ~ 83kHz (Analog/ Digital) |
| V-Scanning Frequency |
56 ~ 75Hz |
| Pixel Frequency |
165 MHz (D-Sub)/135 MHz (HDMI/DVI) |
| Sync Compatibility |
Separate/Composite/SOG |
| Video Input |
RGB Analog/Digital |
| PSM (3 presets + 2 User Defined) |
Presets: Dynamic/Standard/Mild/User1/User2 |
| CSM (3 presets + 1 User Defined) |
Warm/Normal/Cool/User |
| DLTI (Digital Luminance Transient Improver) |
Yes |
| DCTI (Digital Color Transient Improver) |
Yes |
| Color Temperature Control |
Cool/Medium/Warm/User |
| Cinema 3:2/2:2 Pull Down Mode |
Yes |
| Aspect Ratio Correction |
Spectacle/ Full/ Original/ 4:3/ 16:9/ 14:9/ Zoom 1/ Zoom 2 |
| |
|
| CABINET |
|
| |
|
| Speakers/Table Stand Optional |
Yes |
| Cabinet Color |
Black |
| Monitor Dimensions (W × H × D) |
57.3" × 34.8" × 4.7" |
| with Optional Stand & Speakers (W × H × D) |
67.7" × 38.5" × 16.3" |
| Monitor Carton Dimensions (W × H × D) |
62" × 41.2" × 18.2" |
| Monitor Weight |
130.5 lbs |
| Packed Weight |
148.8 lbs |
| VESA Standard Mount Interface |
No, 704 mm × 400 mm (Screw M8) |
| |
|
| ACCESSORIES |
|
| |
|
| Supplied accessories |
Owner’s Manual/Power Cord (6 foot)/ Remote Control (AKB33871403) |
Optional Accessories:
Stand
Speakers |
AP-60DM40
AP-60SM40 |
| |
|
| POWER |
|
| |
|
| Power Consumption |
650W |
| Energy Star Compliant |
No |
| Power Supply |
100-240V~, 50/60Hz |
| Power Switch Type |
Tact Type (In Local Key) |
| |
|
| REAR INPUTS |
|
| |
|
| Component Video & Audio L/R In |
2 Hi-Res (BNC) |
| PC Input via 15-pin female mini D-Sub |
1 (RGB) |
| Composite Video & Audio L/R In |
1 (BNC) |
| Audio In (RGB/DVI with Adapter) |
1 |
| HDTV Formats |
720p/1080i |
| PC Formats |
Auto Scaling to XGA |
| HDMI with HDCP (DVI with Adapter) |
1 |
| RS-232C In (9-pin male D-Sub) |
1 (Service/Control) |
| S-Video In |
1 (S-Video has priority but there is no input mode) |
| Remote Control In (IR) |
1 |
| Discrete IR Input |
Yes |
| |
|
| REAR OUTPUTS |
|
| |
|
| PC Output via 15-pin male mini D-Sub |
1 (RGB) |
| Composite Video & Audio L/R Out |
1 (BNC) |
| RS-232C Out (9-pin female D-Sub) |
1 |
| External Speaker Out Terminals |
Yes (with Amplifier Integration) |
| |
|
| AUDIO |
|
| |
|
| SSM (Sound Status Memory) |
Surround MAX /Flat/ Music/ Movie/ Sports/ User |
| AVL (Auto Volume Limiter) |
Yes (On/Off) |
| Audio Output Power |
20W (10W × 2) |
| Sound Balance (On/Off) |
Yes (for use with optional speakers) |
| |
|
| SPECIAL FEATURES |
|
| |
|
| Temperature Sensor |
Yes |
| Tiling Save & Load |
Yes |
| Vertical Display Mode Menu Rotation |
No |
| Source Selections |
HDMI/DVI, RGB, Component 1 or 2, Composite |
| Brightness/Contrast Control |
Yes |
| Color Control |
Warm, Normal, Cool, and User Control (R/G/B) |
| Tracking (Analog signal) |
Auto Config. or Manual Config. (Clock, Phase) |
| Set-up Language Menu Selection |
English/ French/ Spanish/ Korean/ Italian/ German/ Portuguese/ Japanese/ Chinese |
| XD (LG’s picture improving technology) |
XD Contrast/XD Color/XD NR/MPEG NR |
| Advanced Screen Color Functions |
Cinema, Black Level (Auto, High, Low) |
| Time Functions |
Clock/On Time/Off Time (switches to Standby) |
| Audio Mute |
Yes (select from Remote Control) |
| Sleep Timer Button (on Remote) |
Set timer to switch from On to Off |
| WUXGA Compatible (1920 × 1080p) |
No (Not compatible with 1080p Source Input) |
| Child Lock |
Yes |
| |
|
| STANDARD (CERTIFICATION) |
|
| |
|
| Safety |
UL/c-UL/CB scheme |
| EMC |
FCC Class "Ba"/ CE/MIC |
| RoHS compliant |
Yes |
| |
|
| SERVICE/LIMITED WARRANTY |
|
| |
|
| Limited Warranty |
2 Year Parts/Labor |
| |
|
| OPERATING ENVIRONMENTS |
|
| |
|
| Storage Temperature Range |
-4°F to 140°F (-20°C to 60°C) |
| Storage Humidity Range |
10% to 90% RH |
| Altitude |
Up to 6,561 feet (2,000 m) |
| Operating Temperature |
32°F to 140°F (0°C to 60°C) |
| Operating Humidity Range |
20% to 80% RH |
