FEATURES - Pioneer PDP-434CMX HDTV Plasma TV Monitor
Compatibility with a Wide Range of PC Signals
with a
native resolution of 1024 x 768, this high precision panel can accurately
display personal computer signals ranging from 640 x 400 and 640 x 480(VGA)
to 1024 x 768 (XGA) and 1280 x 768 (WXGA). This unit can also display (SXGA)
resolutions of 1280 x 1024 and (UXGA) 1600 x 1200.
2 x 2 Inage Expansion
This mode allows a 2 x 2 data wall using four units without the need for
an expansion device. Two display modes are available, one that enlarge all
picture elements so the entire picture is visible, and one that enlarges the
whole image so lines between units are not visible.
Intelligent Auto Setup
The Intelligent Auto Setup feature improves both performance and
convenience, allowing image adjustment via the remote control. This display
incorporates a new function, Auto Adjust, which detects the PC signal and
automatically adjusts the position of the image, making it unnecessary to
have to push the auto setup button.
Three
Dual Picture Modes
The
PDP-434CMX offers a choice of three Dual Picture modes for simultaneous
display of images from two connected sources. Split screen shows two images
side by side, Picture in Picture superimposes a small picture over the full
screen picture in any of four comers, and Picture out Picture displays the
second image on the right side of the screen.
Color Detail Adjustment
Color adjustment can be performed for any specific color without
affecting the other colors. For example, you can change the purplish red of
a sports car to crimson without changing other colors in the image.
Enhanced Point Zoom
The Enhanced Point Zoom Function lets you instantly expand any portion
of a PC image in three steps (1.5x, 2x, 3x) great for emphasizing key points
in presentations. The Zoom Area sub-display area makes it easy to confirm
the expanded portion.
Large GUI Display
Having a GUI display is a definite advantage, making operation considerably
easier, but if it is too small to see when the unit is mounted, it
usefulness is limited. The PDP-434CMX provides an extra-large display, which
is visible even when the unit is mounted in a high location.
Function Lock
A number of functions can be locked, making the display system more
secure. Lock modes are on/off, main unit buttons, remote control, main unit
buttons plus remote control, and memory lock, which selects input and volume
default settings when the unit is turned on.
Extremely Low Power Consumption
This PDP-434CMX consumes only 298W of power while producing bright images.
This is extremely low for a 43-inch WXGA-class plasma display. Standby power
is a mere 0.8W. in addition the PDP-434CMX satisfies the standards of the
international Energy Star Program.
Four Energy Save Modes
In addition to the normal operating mode, the PDP-434CMX provides a choice
of four energy saving modes that further reduce power consumption. These
modes are power save, intermediate linear brightness, which decreases the
peak intensity of high brightness images and auto brightness control, which
uses a sensor to automatically adjust the brightness depending upon room
lighting.
Three Image Burn-In Prevention Modes
The PDP-434CMX employs powerful tools to prevent burn-in. These include RGB
separate full mask side mask brightness adjustment. Orbiter mode for
one-pixel-at-a-time movement of displayed images at fixed intervals, and an
inverse mode that displays images as negative. Full mask and inverse can be
controlled by the on/off timer via the Screen Management function.
Peak Pattern Detection System
this system also helps to prevent burn-in monitoring the prolonged
display of still images and the concentration of brightness in any segment
of the panel.
Smart Cooling System
Internal fans are activated only when needed, keeping fan noise to a
minimum and conserving power.
Display of Error Information
in order to minimize downtime, the PDP-434CMX provides comprehensive
error information on the screen. Many different errors, their causes, and
part serial numbers can be displayed and identified by symbols, in addition,
various errors are indicated by the two front LEDs, so even if the display
malfunctions, the cause can be quickly identified and corrected.
RS-232C Get Command
The PDP-434CMX can transmit various information to a PC via the RS-232C
link using the Get command, including power on/off, input number, signal
detection and complete error data. This ensures that remote monitoring is
worry-free.
Expandability to Meet a Wide Variety of Present and Future Needs ES Card
Slot Interface
The PDP-434CMX is designed to be ready for any type of application with
the integration of two ES Card Slot interfaces, one for communication and
one for enhances data. The PDP-434CMX comes supplied with a communication
card that includes RS-232C and combination I/O interfaces. This card can be
removed. The second slot can be used to enable video capabilities through
the input of a wider range of analog or digital signals, and additional
control. As a result, one PDP-434CMX can be used for multiple tasks,
including various applications that other PDP’s can’t handle. You can use it
any way you need to, and it is also ready for additional tasks you may
develop in the future.
|
